SİLİNDİR BAŞLI İTİCİ PİM

DIN 1530, type A, nitrided & oxidized (similar DIN ISO 6751)
Hardness / Sertlik Material
Material / Malzeme Sıcaklık Takım İş Çeliği / Hot working tool steel
d1 g6 d2 0-0,2 d4 max. k 0-0,05 r+0,20 I3 I1+0,20 100 125 160 200 250 315 400 500 630 800 1000
1 2.5 1.03 1.2 0.2 5 ● ● ● ●
1.5 3 1.53 1.5 0.2 5 ● ● ● ● ●
2 4 2.03 2 0.2 5 ● ● ● ● ● ● ●
2.5 5 2.53 2 0.3 5 ● ● ● ● ● ●
3 6 3.03 3 0.3 5 ● ● ● ● ● ● ● ●
3.5 7 3.53 3 0.3 5 ● ● ● ● ● ● ● ● ●
4 8 4.03 3 0.3 5 ● ● ● ● ● ● ● ● ● ●
4.5 8 4.53 3 0.3 5 ● ● ● ● ● ● ● ● ●
5 10 5.03 3 0.3 5 ● ● ● ● ● ● ● ● ● ●
5.5 10 5.53 3 0.3 5 ● ● ● ● ● ● ● ● ● ●
6 12 6.03 5 0.5 5 ● ● ● ● ● ● ● ● ● ● ●
6.5 12 6.53 5 0.5 6 ● ● ● ● ● ● ● ● ● ● ●
7 12 7.03 5 0.5 6 ● ● ● ● ● ● ● ● ● ● ●
7.5 12 7.53 5 0.5 6 ● ● ● ● ● ● ● ● ●
8 14 8.03 5 0.5 8 ● ● ● ● ● ● ● ● ● ● ●
8.5 14 8.53 5 0.5 8 ● ● ● ● ● ● ● ● ● ●
9 14 9.03 5 0.5 8 ● ● ● ● ● ● ● ● ● ●
10 16 10.04 5 0.5 10 ● ● ● ● ● ● ● ● ● ● ●
10.5 16 10.54 5 0.5 10 ● ● ● ● ● ● ● ● ● ● ●
11 16 11.04 5 0.5 10 ● ● ● ● ● ● ● ● ● ●
12 18 12.04 7 0.8 12 ● ● ● ● ● ● ● ● ● ● ●
14 22 14.04 7 0.8 14 ● ● ● ● ● ● ● ● ● ● ●
16 22 16.04 7 0.8 16 ● ● ● ● ● ● ● ● ● ● ●
18 24 18.07 7 0.8 18 ● ● ● ● ● ● ● ● ● ● ●
20 26 20.07 8 1.1 20 ● ● ● ● ● ● ● ● ● ●
25 32 25.1 10 1.1 25 ● ● ● ● ● ● ● ● ●
32 40 32.1 10 1.1 32 ● ● ● ● ● ● ● ●
