D71.051 Grafitli Döküm Set - Guide Bearing Set Non-Lubricant
Malzeme - Material GG25 / SAE 430B / 1.1213 (Cf 53)
Sertlik - Hardness HB≥180 / 62± 2 HRC
Isıl İşlem - Heat Treatment Indüksiyon (Induction)
| a | b | d | d1 | e1 | e2 | h | h1 | M | I | Sipariş Kodu | Order Code |
|---|---|---|---|---|---|---|---|---|---|---|
| 130 | 75 | 40 | 10 | 100 | 44 | 70 | 25 | 12 | 160 | D71.051_40160 |
| 180 | D71.051_40180 | |||||||||
| 200 | D71.051_40200 | |||||||||
| 225 | D71.051_40225 | |||||||||
| 250 | D71.051_40250 | |||||||||
| 280 | D71.051_40280 | |||||||||
| 130 | 75 | 40 | 10 | 100 | 44 | 50 | 25 | 12 | D71.10_40 | |
| 155 | 90 | 50 | 10 | 125 | 60 | 85 | 25 | 12 | 160 | D71.051_50160 |
| 180 | D71.051_50180 | |||||||||
| 200 | D71.051_50200 | |||||||||
| 225 | D71.051_50225 | |||||||||
| 250 | D71.051_50250 | |||||||||
| 280 | D71.051_50280 | |||||||||
| 315 | D71.051_50315 | |||||||||
| 155 | 90 | 50 | 10 | 125 | 60 | 70 | 25 | 12 | D71.10_50 |
